GYG52 Series Only One - Coated PM60 Square Endmill 4 Flute Short Length (Center Cut) YG-1

GYG52 Series Only One – Coated PM60 Square Endmill 4 Flute Short Length (Center Cut) YG-1

Type : Square
Flute : 4
Cutting Edge shape : Square
Helix Angle : 35°/37°
Size min : D3.0
Size max : D25.0

Brand: YG1
Series: Only One
Flute: 4
Application: Perfect solution to protect Carbide chipping problems under vibrations
Coating: Y-Coating
Suitable for Material: Steel, stainless steel, Cast Iron, Copper alloys, Hardened Steel
Distributor: PT. DAI STAR INDONESIA

Spesifikasi GYG52 Series Only One – Coated PM60 Square Endmill 4 Flute Short Length (Center Cut) YG-1

EDP No.	Mill Diameter	Shank Diameter	Length of Cut	Overall Length	Chamfer
EDP No.	^D1	^D2	^L1	^L2	Chamfer
GYG52030	3.0	6	8	52	0.1
GYG52040	4.0	6	11	55	0.1
GYG52050	5.0	6	13	57	0.1
GYG52060	6.0	6	13	57	0.1
GYG52070	7.0	8	16	66	0.1
GYG52080	8.0	8	19	69	0.1
GYG52090	9.0	10	19	69	0.1
GYG52100	10.0	10	22	72	0.1
GYG52120	12.0	12	26	83	0.1
GYG52140	14.0	12	26	83	0.2
GYG52160	16.0	16	32	92	0.2
GYG52180	18.0	16	32	92	0.2
GYG52200	20.0	20	38	104	0.2
GYG52220	22.0	20	38	104	0.2
GYG52250	25.0	25	45	121	0.2

Kami adalah Distributor Resmi produk YG-1 GYG52 Series Only One – Coated PM60 Square Endmill 4 Flute Short Length (Center Cut). Produk YG-1 adalah salah satu Brand yang sudah dikenal di seluruh dunia serta sudah banyak di gunakan oleh berbagai industri manufktur dengan beragam jenis dan kegunaan yang bermacam-macam.
