GYF95 Series Only One - Coated PM60 Corner Radius Roughing Endmill Short Length (Center Cut) YG-1

GYF95 Series Only One – Coated PM60 Corner Radius Roughing Endmill Short Length (Center Cut) YG-1

Type : Corner Radius Roughing
Flute : Multi Flute
Cutting Edge shape : Corner Radius Roughing
Helix Angle : 4F : 44°/45°
5F : 44°/44.5°/45°
Size min : D2.0
Size max : D25.0

Brand: YG1
Series: Only One
Flute: Multi Flute
Application: Perfect solution to protect Carbide chipping problems under vibrations
Coating: Y-Coating
Suitable for Material: Steel, stainless steel, Cast Iron, Copper alloys, Hardened Steel
Distributor: PT. DAI STAR INDONESIA

Spesifikasi GYF95 Series Only One – Coated PM60 Corner Radius Roughing Endmill Short Length (Center Cut) YG-1

EDP No.	Mill Diameter	Shank Diameter	Length of Cut	Overall Length	Chamfer
EDP No.	^D1	^D2	^L1	^L2	Chamfer
GYG52030	3.0	6	8	52	0.1
GYG52040	4.0	6	11	55	0.1
GYG52050	5.0	6	13	57	0.1
GYG52060	6.0	6	13	57	0.1
GYG52070	7.0	8	16	66	0.1
GYG52080	8.0	8	19	69	0.1
GYG52090	9.0	10	19	69	0.1
GYG52100	10.0	10	22	72	0.1
GYG52120	12.0	12	26	83	0.1
GYG52140	14.0	12	26	83	0.2
GYG52160	16.0	16	32	92	0.2
GYG52180	18.0	16	32	92	0.2
GYG52200	20.0	20	38	104	0.2
GYG52220	22.0	20	38	104	0.2
GYG52250	25.0	25	45	121	0.2

Kami adalah Distributor Resmi produk YG-1 GYF95 Series Only One – Coated PM60 Corner Radius Roughing Endmill Short Length (Center Cut). Produk YG-1 adalah salah satu Brand yang sudah dikenal di seluruh dunia serta sudah banyak di gunakan oleh berbagai industri manufktur dengan beragam jenis dan kegunaan yang bermacam-macam.
